TP4056 USB-C Charging Module – Lithium Battery Charger with USB Type-C Port
₹15.0
Prices include applicable taxes.
2 sold
Only 498 left!
Check Delivery Availability
The TP4056 USB-C Charging Module is a compact and efficient lithium-ion battery charger module with a USB Type-C input port. It is widely used for charging single-cell 3.7V Li-ion or Li-polymer batteries, providing safe, reliable, and automatic charging with built-in overcharge protection.
No reviews yet. Be the first to review!
Product Specifications
| Specification | Details |
|---|---|
| Charging IC | TP4056 |
| Input Voltage | 5 V DC via USB Type-C port |
| Charge Current | Adjustable, typically 1A |
| Battery Type Supported | Single-cell Li-ion / Li-Po (3.7V) |
| Charging Mode | Constant Current / Constant Voltage (CC/CV) |
| Protection Features | Overcharge, overdischarge, overcurrent, short circuit protection |
| Indicator LEDs | Red (Charging), Green (Charge Complete) |
| Dimensions | Approx. 32mm x 18mm x 5mm |
Key Features
- USB Type-C port for modern and reversible charging connection
- Constant current / constant voltage charging method for battery safety
- Automatic charge termination when battery is full
- Built-in safety protections to extend battery life and prevent damage
- Compact and lightweight module for easy integration into projects
- Standard TP4056 features with upgraded USB-C connectivity
- Compatible with 3.7V single-cell lithium-ion and lithium-polymer batteries
Applications
- Rechargeable battery packs for DIY electronics
- Portable power banks and battery chargers
- IoT devices and wearables requiring battery charging
- Arduino, Raspberry Pi, and ESP32 powered battery systems
- Small robotics and portable gadgets with lithium batteries
Frequently Asked Questions
Yes, it is designed specifically for single-cell 3.7V Li-ion or Li-Po batteries.
The charging current is typically set to 1A but can be adjusted by changing the resistor on the module.
Yes, USB-C provides a reversible connector for easy plugging.
Yes, the module includes built-in overcharge and short-circuit protections.
